Colorlight E320
identity
- name
- E320
- vendor
- Colorlight
- family
- colorlight
- id
- none stated
- status
- generates
- file
- config/cards/e320.toml
- image pattern
- E320_PWM_FPGA{version}_*.hex
- sdram staging
- true
- notes
- Specification: Colorlight publishes no E320 specification any more. Its downloads page (https://en.colorlightinside.com/service/download/?cat=602) carries E120, E80 and E320Pro only, and the Chinese page (https://www.colorlightinside.com/service/download/?cat=602) carries the newer E80-G2 / E120-G2 / E160-G2 / E320Pro generation. E320Pro is a separate 2025 product and is NOT this card. So the limits below are tier-2: - Control area, Normal 128x1024 / PWM 256x1024 / Shixin 162x1024: https://www.led-card.com/colorlight-e320-receiver-card.html, whose text is the vendor's own overview paragraph with the E320 numbers substituted (compare the E120 PDF's "Overview" and "Basic parameters"). A second reseller, https://www.ledwallcentral.com/ColorLight-E320-receiving-card.htm, agrees on 256x1024. - 8 HUB75 ports ("HUB 75 (16 pin) x 8"): https://www.ledwallcentral.com/ColorLight-E320-receiving-card.htm. Unresolved: the Shixin figure, 162x1024, is the same number the E120 PDF gives for the E120, where every other E320 figure is larger than the E120's; it may be a copy from the E120 sheet. It is not used here (max_height is the PWM figure). Board dimensions conflict between resellers (145.2x91.7x18.4mm vs 150x60x15mm) and are not recorded. No PCB revision and no cascade limit are stated anywhere. Firmware: Colorlight's "75B E80 75E E120 E320 5-in-1 Series" archive holds one image set for the whole classic family. Its 129 files (config/firmware.toml) are filed by driver chip and build variant only -- Custom Series/<chip>, PWM/<chip>, Regular, SHIXIN, Irregular Display Firmware -- with no folder, file name or bitstream header naming a card model, and every file is the same 721,024-byte LFE5U-25F bitstream. Every build is named E320 whatever card it runs on. Memory map, guarded blocks and boot-image offsets: copied from config/cards/e120.toml. INFERRED from that shared firmware, not measured on an E320. The addresses were dumped from one E120 (docs/fpga/flash-layout.md); nothing here has been read off an E320, which is why status is "generates".
limits
- max width
- 1024 px
- max height
- 256 px
- hub ports
- 8
memory map
- block bytes
- 0x10000
- primary bank
- 0x000000, 0x0b0000 bytes, 11 blocks
- golden bank
- 0x200000
- parameter block
- 0x07 (block 7)
- eeprom mirror
- 0x07f000
- guarded from 16.53
- 0x00, 0x01, 0x02, 0x08
boot image offsets
- basic_pack
- 0x0000
- data_swap
- 0x0500
- module_positions
- 0x0600
- chip_page
- 0x0900
- void_line
- 0x1000
- void_line_columns
- 0x1400
- anti_void
- 0x1800
- mapping
- 0x3000
- scan_table
- 0x6000
- rcvbp
- 0x8000
- map_entries
- 4096
- rcvbp_max
- 0x6ffc
Tested panels
none
Firmware
129 images with their versions, driver chips and checksums.
